Blackmagic Videohub Rentals
20×20 • 40×40 • 80×80
Signal routing built around your production.
Compare 20×20, 40×40 and 80×80 12G-SDI router rentals for live events, broadcast and corporate productions.
3 sizes
20×20, 40×40, 80×80
12G-SDI
SDI routing
UHD60
Up to 2160p60
1–4RU
Choose your capacity
Choose your Blackmagic SDI router rental
HRE carries Blackmagic Videohub 20×20, 40×40 and 80×80 12G routers. Start with your source and destination counts, then allow room for backup feeds, recording paths and changes during the show.
The individual model pages below make it easy to compare capacity and request the right rental. For HDMI or DisplayPort connections, explore our Lightware MX2 rentals.
Compare the three rental models
Technical Specifications
Rental models
20x20, 40x40 and 80x80 12G
Video connections
BNC SDI inputs and outputs
Video formats
SD, HD and Ultra HD up to 2160p60
20x20 chassis
1RU; single power supply
40x40 chassis
2RU; redundant power supplies
80x80 chassis
4RU; redundant power supplies
Control options
Front panel or Ethernet
Signal planning
No input resynchronization or scaling
Which Videohub sizes can I rent?
HRE rental inventory includes the 20×20, 40×40 and 80×80 12G models. Check the individual pages below and request availability for your dates.
Can I route different SDI formats at the same time?
Yes. These models accept different supported SDI standards on different inputs. Routing does not convert the signal, so each destination must accept the incoming format.
Does a Videohub provide seamless switching or scaling?
These models have no input resynchronization. They are routing matrices, not presentation scalers or production switchers. Include any clean-switching, synchronization or format-conversion requirements in your request.
What should I send for a rental quote?
Send your dates, preferred model, source and destination list, resolution, frame rate and cable distances. Include a signal-flow drawing if available and note any control panels, cabling, conversion or technical support you need.
Can HRE help with the rest of the system?
Tell us about your complete production so we can help scope the routing alongside switching, playback and recording. Additional equipment and support can be quoted to your requirements.
